AS3400 L3 Switch

The ACT 1RU AS3400 P2P Switch Platform is a series of high performance L2/L3 switches which provide network operators and services providers with a powerful aggregation layer for Gigabit Ethernet P2P services in Fiber to The Home/Business (FTTH & FTTB) networks.

    24 10GE/GE SFP+ ports, 4 100GE/40GE QSFP ports

    Supports 32K MAC

    Supports STP/RSTP/MSTP protocols, VRRP protocol, Ethernet ring protection, dual master-slave uplink protection, and LACP link aggregation

    Supports ISSU (In-Service Software Upgrade)

    Supports an ultra-high BFD dual-directional link detection mechanism

    Supports Ethernet OAM mechanism, 802.3ah, 802.1ag, and ITU-Y.1731

    Supports layer-2 and layer-3 routing protocols

    Supports IPv6 protocol suite, IPv6 neighbor discovery, ICMPv6, path MTU discovery, DHCPv6, etc.

    Intelligent power supply management system

    Intelligent fan management system

    Complies with IEEE 802.3az


Item

Description

Interface

24 × 10GE/GE SFP+ ports,

4 × 100GE/40GE QSFP28 ports

Console

1 × RJ45 port

1 × MGMT port

Backplane

800 Gbps

Forwarding Rate

600 Mpps

Chassis Dimensions

440 mm × 350 mm × 44 mm

Chassis Weight

7.1 kg

Package Dimensions

576 mm × 448 mm × 94 mm

Package Weight

8.3 kg

Power Consumption

No‑load: 45 W

Full‑load: 70 W

Power Supply

AC: 100 V to 240 V, 50 Hz ± 10 %

Dual‑power AC

Total Output BTU

238.91 (1000 BTU/hr = 293 W)

Fan Number

4

Noise @ 25 °C

57 dBa

MTBF

>100,000 hr

Forwarding Mode

Store‑forward

Flash

32 MB

DRAM

1024 MB

MAC

32K

Jumbo Frame

9K

Routing Table

IPv4: 16K

IPv6: 12K

ARP Tables

IPv4: 10K

IPv6: 10K

Total SVI

1K



Features

VLAN

4K Active VLAN, QinQ & Selective QinQ, GVRP, Private VLAN

Spanning Tree

802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)

BPDU guard, root guard and loopback guard

Multicast

PIM‑SM, PIM‑DM, IGMP v1/v2/v3

IGMP Snooping, IGMP Fast Leave, MVR, IGMP filter

IPv4

Static routing, RIP v1/v2, OSPF, BGP, PBR, ECMP

BFD for OSPF, BGP

IPv6

ICMPv6, DHCPv6, ACLv6 and IPv6 Telnet

IPv6 neighbor discovery, Path MTU discovery

MLD V1/V2, MLD snooping

IPv6 Static Routing, RIPng, OSPFv3, BGP4+

Manual tunnel, ISATAP tunnel, 6 to 4 tunnels

MPLS

LDP protocol, Multi‑VRF

MPLS L2 VPN

QoS

CAR, HQoS, MAC/IP/TCP/UDP/VLAN/ COS/DSCP/TOS based QoS, 802.1P/ DSCP

priority re‑labeling, SP, WRR, and “SP+WRR”, Tail‑Drop, WRED, flow monitoring and traffic shaping

Management

Console, Telnet, SSH v1/2, HTTP, HTTPS

SNMP v1/v2/v3, RMON

TFTP, FTP, SFTP

NTP, SPAN, RSPAN

Security

Port isolation, Port security, and “IP+MAC+port” binding, MAC sticky

DHCP Snooping and option 82, DAI & IP source guard, PPPoE+

IEEE 802.1x, RADIUS, and TACACS+

L2/L3/L4 ACL flow identification and filtration

Anti‑attack from DDoS, TCP’s SYN Flood, UDP Flood, etc.

Broadcast/multicast/unknown unicast storm‑control

MD5, SHA‑256, RSA‑1024, AES256, etc.

Reliability

Static/LACP link aggregation,

Interface backup

BVSS virtual‑stacking

EAPS and ERPS

URPF, LLDPISSU

VRRP

1+1 power backup

Certifications

CE, FCC, RoHS
