AT5000 ARQR Receiver

AT5000 1RU Quad Return Receiver offers a flexible, low noise, high performance return receiver platform for regular CATV or RFoG return path application and long distance CWDM/DWDM return data transmission for digital CMTS services in CATV networks. Together with ACT 1RU AT5000 XMOD and EDFA optical amplifiers, the 1RU ARQR return receiver provides an ideal long distance video and short, medium video overlay solution in traditional HFC network and also high density FTTX networks to bring back the data signal from business and subscriber home premises.

•    Compatible with FTTX PON, EPON, GPON, BPON, DPON application

•    High Performance, Low Noise RFoG Return Receiver

•    Four Independent Receivers in 1RU Chassis

•    Bandwidth 5 to 100MHz for RFoG or 200MHz for Standard RRX

•    Suitable for RFoG or long-distance return CWDM/DWDM applications

•    Dual redundant hot-swappable AC or DC power supplies

•    Front-panel LCD for local monitoring of transmitter status

•    Local or remote monitoring and configuration

•    SNMP/HTTP monitoring, management and control

AT5000 Analog Return Quad Receiver, ARQR

Item

Description

Remarks

Optical Parameters

Working Wavelength

1200 nm to 1600 nm


Optical Reflection

>45 dB


Optical Input Power

+0 dBm to ‑25 dBm

‑

AGC Control

+0 dB to ‑20 dB


Fiber Connector

FC/APC or SC/APC


RF Parameters

Work Bandwidth

5 MHz to 200 MHz


Flatness

±0.75 dB


Return Loss

≥16 dB


Output Impedance

75 Ω


Output Level

≥104 dBµV


RF Test Port

‑20 dB ± 1 dB

On front panel

Output Level Adjust Range

0 dB to 20 dB

AGC mode

Output Level Adjust Range

0 dB to 31 dB

AGC mode

Working Mode

AGC or MAC


 General Parameters

Working Temperature

‑5 °C to +50 °C


Storage Temperature

‑30 °C to +70 °C


Relative Humidity

5 % to 95 %


Dimensions (L×W×H)

483 mm× 350 mm × 44 mm

19”

Power Consumption

<22
